U3560 BMW Fault Code

Description:

Variable Cam Timing Over-advanced (Bank 1) The comprehensive component monitor (CCM) monitors the VCT position for an over-advanced camshaft timing.
The test fails when the camshaft timing exceeds a maximum calibrated value or remains in an advanced position.

BMW cam timing improperly set No oil flow to the VCT piston chamber Low oil pressure VCT solenoid valve stuck closed Camshaft advance mechanism binding (VCT unit) U3560 DTC is a check of the VCT unit.

U3560 Code Symptoms :

OBD U3560 code and tailpipe testing are two different approaches to identify vehicles in need of repair. The OBD system looks for broken or malfunctioning emissions control components and U3560, while tailpipe tests sample a vehicle's exhaust to see if it is above or below certain prescribed limits. Given the robust nature of today's emissions control components, it is entirely possible for an individual component to malfunction without leading to an immediate increase in emissions at the tailpipe.

In such cases, other components (like the catalyst) can temporarily compensate for the part that is broken however, these other components can only do double duty for so long before they, too, begin to malfunction. In addition, OBD also monitors for and other malfunctions in the fuel system problems that traditional tailpipe tests were not designed to identify. Most state and local areas also include a gas cap pressure test as part of an emission inspection.

Diagnosis And Repairing U3560

U3560 OBD2 reports a sensor fault, replacement of the sensor is unlikely to resolve the underlying problem. The fault is most likely to be caused by the systems that the sensor is monitoring, but might even be caused by the wiring to the sensor itself.

How to fix U3560 code ?

• Erratic camshaft position due to low oil pressure
• Faulty front heated oxygen sensor
• 1Camshaft Position Sensor circuit poor electrical connection
• Damaged ECM

As long as the throttle plate remains closed, the idling speed and quality is controlled by the PCM via the idle control valve, and as can be seen from the above it should be clear that idle control on a gasoline engine is a complex affair.

For instance, if the engine is started in sub-zero temperatures, the PCM will command the idling control valve to allow less air to enter the engine to enrich the air/fuel mixture to create a condition which is roughly analogous to how chokes worked on carburetted engines to control idling in cold weather.
